2.0*5.2mm Pullable Bullet SCAPC to SC/APC FTTH Drop Cable Fiber Optic Patchcord SM G657A2

  • 1
  • 2

Intertion Loss : ≤0.3dB

Place of Origin : China

Wavelength : 1310nm,1550nm

Operation Temperature : -20℃~70℃

Payment Terms : Western Union,T/T,/Paypal

Length : 5M or Customized

Diameter : 2.0*5.2mm

Product Name : 2.0*5.2mm Pullable Bullet SCAPC to SCAPC FTTH Drop Cable Fiber Optic Patchcord SM G657A2

Connector Type : APC

Model Number : TK-PC-SAP-SA-AS-3.0-TPU

Color : Black

Certificate : CE/ROHS/REACH

MOQ : 100PCS

Packaging Details : Export Standard Packing

Jacket Material : LSZH

Certification : CE/ROHS/REACH/ISO9001/ISO14001

Supply Ability : 5000PCS/Day

Grade : Telecom Grade

Brand Name : DF/OEM/Nuetral

Price : US$0.01~4.69/PC

Fiber Type : OS2, G652D , G657A1 , G657A2 , G657B3

Delivery Time : 5-9 working days depends on QTY

Fiber Diameter : 9/125

Return Loss : APC SM ≥ 60dB

Production Capcity : 10000PCS/Day

Contact Now

2.0×5.2mm Pullable Bullet SC/APC to SC/APC FTTH Drop Cable Fiber Optic Patchcord SM G657A2
Product Description

Takfly Bullet Pushable cable assemblies offer a flexible, pushable pre-terminated fiber optic drop solution for fast and reliable FTTX deployments. The bullet pushable connector enables the pre-connectorized cable to be installed through microducts and small holes that are typical of most FTTX scenarios. This cable can be installed without using large conduits or drilling big holes through the customer's wall.

This bullet Pushable assembly can be successfully pushed through small holes and microduct. Hand push distances vary according to bend frequency and duct quality. The rugged round drop cable with the pushable pre-terminated connector reduces the cost of fiber deployments as well as the intrinsic skill and difficulty of handling and connecting customer drop cables.

Fiber Optic Attributes
  • Mode field diameter: 8.6μm ± 0.4μm at 1310nm
  • Cladding diameter: 125.0μm ± 0.7μm
  • Coating diameter: 245μm ± 10μm
  • Coating-cladding concentricity error: ≤ 12.5μm
  • Cut-off wavelength: ≤ 1260nm
  • Attenuation coefficient: 1310 ≤ 0.4dB, 1550 ≤ 0.3dB
FTTH Cable Information
  • Number of fiber: 1 core
  • Fiber type: G657A1
  • Strength member material: FRP
  • Diameter: 0.5mm × 2
  • Self-support messenger wire: Steel wire, 1.0mm diameter
  • Outer sheath: LSZH Black
  • Cable size: 5.0 × 2.0mm
Connector Test Specifications
Item Specifications
Type SC/APC (1310)
Insertion Loss ≤ 0.3 dB + 0.36 dB/km × L(km) @ 1310nm
≤ 0.3 dB + 0.25 dB/km × L(km) @ 1550nm
Return Loss ≥ 60dB
Endface IEC 61300-3-35
Durability (1000 Mating) 0.2dB Max. increase
Installation Temperature -10℃ ~ +60℃
Operating Temperature -25℃ ~ 70℃
Storage Temperature -40℃ ~ 75℃
Cable pull 90N
Optical Fiber Performance
Parameter Long Term Short Term
Tensile strength (N) 200 500
Crush load (N) 1000 2000
Wavelength (nm) 1310/1550
Attenuation (dB) 0.4/0.3
Cladding diameter (μm) 125 ± 1
Cladding non-circularity ≤ 1.0%
Coating diameter (μm) 242 ± 7
Detailed Technical Parameters
NO. Item Unit Specification (SM G657A2)
1 Mode Field Diameter (1310nm) μm 8.2~9.0
1 Mode Field Diameter (1550nm) μm 9.1~10.1
2 Cladding Diameter μm 125 ± 0.7
3 Cladding Non-Circularity % ≤ 0.7
4 Core-Cladding Concentricity Error μm ≤ 0.5
5 Coating Diameter μm 245 ± 5
6 Coating Non-Circularity % ≤ 6.0
7 Cladding-Coating Concentricity Error μm ≤ 12
8 Cable Cutoff Wavelength nm λcc ≤ 1260
9 Attenuation (Max) 1310nm dB/KM ≤ 0.36
9 Attenuation (Max) 1550nm dB/KM ≤ 0.25
10 Macro-Bending Loss (1 Turn × 7.5mm radius @1550nm) dB ≤ 0.08
10 Macro-Bending Loss (1 Turn × 7.5mm radius @1265nm) dB ≤ 0.25
Applications
  • CATV
  • Telecommunication networks
  • Active device termination
  • Local area networks (LANS)
  • Data processing networks
  • Test equipment
  • Wide area networks (WANS)
Product Features
  • Low insertion loss and High reflection loss
  • Good exchange ability
  • Good durability
  • High temperature stability
  • Standard: Telcordia GR-326-CORE
2.0*5.2mm Pullable Bullet SCAPC to SC/APC FTTH Drop Cable Fiber Optic Patchcord SM G657A2
